System Design: Robinhood-Style Retail Trading Platform

Design a retail brokerage for equities/options/crypto with mobile clients, real‑time quotes, order placement, portfolio, funding, and regulatory/compliance controls.

Product scope and requirements

Functional

Accounts: KYC, funding (ACH/cards), portfolios, balances, tax lots.
Market data: top‑of‑book quotes, candles, depth (level 2 optional), news.
Trading: market/limit/stop, GTC/day, options (calls/puts), crypto spot.
Risk/compliance: PATTERN‑DAY‑TRADER checks, buying power, margin, Reg‑T/Reg‑NMS, surveillance.
Notifications: fills, corporate actions, margin calls, price alerts.

Non‑functional

Latency: quote < 300 ms P95 to device; order ACK < 200 ms; fill notification < 1 s.
Availability: 99.9%+ core during market hours; graceful degradation off‑hours.
Consistency: strong within order state and balances; eventual for analytics/feeds.
Throughput: 100k+ concurrent users; 10k+ orders/min bursts on events.

Out of scope

Matching engine (we route to venues/MMs/crypto exchanges).

High‑level architecture

Mobile/Web
   │
API Gateway (AuthZ, rate limit, routing)
   │
   ├── Market-Data API  ──► Quote Cache (Redis/Mem) ──► Market Data Ingest (Kafka) ─► Normalizers
   ├── Trade API        ──► OMS (Orders/Risk) ───────► Venue Routers ──► Exchanges/MMs
   ├── Portfolio API    ──► Positions, Cost Basis, PnL (Postgres + CQRS cache)
   ├── Accounts API     ──► KYC/Funding (ACH/Card), Ledgers (Double‑entry)
   └── Notify API       ──► Push/Webhooks/Email/SMS

Core Streams: Kafka topics (quotes, trades, fills, balances, audit)
State Stores: Postgres (ACID), Redis (hot), S3 (history), ClickHouse (analytics)
Secrets: KMS/HSM; Feature Flags: Consul

Market data ingestion and delivery

Feeds: SIP/OPRA/Direct, crypto exchange websockets.
Normalization: parse → validate → enrich (symbol map) → publish to Kafka quotes.v1, trades.v1.
Caching: in‑memory fanout service maintains latest NBBO/top‑of‑book per symbol; updates Redis for API fallback.
Delivery: clients subscribe via server‑side websockets or poll; use delta compression and backpressure.

Latency path (quote) 1) Feed → Normalizer (<10 ms parse) 2) Kafka → Fanout (p99 < 50 ms) 3) Fanout → Client WS (edge POPs/CDN websockets where applicable)

Order flow and OMS (Order Management System)

States: New → Accepted → Routed → PartiallyFilled/Filled → Canceled/Rejected

Workflow 1) Pre‑trade checks: auth, account status, symbol eligibility, market hours. 2) Buying power: compute in real‑time (cash/margin, option requirements, crypto balances). 3) Risk rules: PDT, max order size/notional, volatility guards, concentration limits. 4) Persistence: create Order row (Postgres) in a transaction with idempotency key. 5) Routing: choose venue/MM via smart‑router (fees, price improvement, liquidity). 6) Ack to client; async fills via venue FIX/WebSocket → Fill Handler → OMS. 7) Balance/position updates: double‑entry ledger; tax‑lot selection (HIFO/Specific ID).

Data model (simplified)

orders(id, account_id, symbol, side, type, qty, limit_price, time_in_force, state, venue_id, created_at, ...)
fills(id, order_id, venue, qty, price, ts)
positions(account_id, symbol, qty, cost_basis, updated_at)
ledger(id, account_id, delta_cash, delta_margin, reason, ref_id, ts)

Idempotency

Client sends Idempotency-Key per order; OMS enforces uniqueness with unique index; safe retries.

Risk and compliance

Real‑time checks in OMS; slow/surveillance in async jobs.
Margin engine: requirements per asset class; overnight vs. day.
Pattern Day Trader: track intraday round trips; lock accounts exceeding thresholds.
Reg‑NMS/Best‑ex: capture quotes at order time; venue decision audit trail.
AML/Fraud: velocity, device fingerprinting, sanctions screening.

Portfolio, PnL, and cost basis

CQRS: write model in Postgres (positions/ledger), read model cached in Redis for fast portfolio loads.
Tax lots: lot table with FIFO/HIFO; corporate actions processor adjusts lots (splits/dividends).
PnL: intraday via mark‑to‑market (latest quote); end‑of‑day snapshots to S3 for statements.

Accounts, funding, and ledgers

KYC/AML onboarding; Plaid/ACH micro‑deposits or instant auth; card pushes for small amounts.
Double‑entry ledger ensures debits=credits (cash, unsettled, margin interest, fees).

Reliability and scale

Backpressure: shed quote fanout for non‑subscribed symbols; rate‑limit order spam per account.
Graceful degradation: if real‑time feed down, fall back to last quote + warning banner.
Regional redundancy: active‑active read (market data); active‑passive for OMS (to avoid split‑brain).
Replayable streams: Kafka with compaction/retention; rebuild read models from topics.

Consistency model

Strong consistency for orders/fills/balances within OMS transaction boundaries.
Eventual consistency for derived views (portfolio charts, analytics).

Security and privacy

OAuth2/OIDC; device binding; WebAuthn for step‑up.
Secrets in KMS/HSM; PII encryption at rest; PCI DSS for card data.
Least privilege between services; audit logs immutable (WORM storage).

APIs (examples)

POST /v1/orders
{
  "symbol": "AAPL", "side": "buy", "type": "limit", "qty": 10, "limit_price": 180.00, "time_in_force": "day"
}

GET /v1/quotes?symbols=AAPL,TSLA
GET /v1/portfolio
GET /v1/orders/{id}

WebSocket events

{ "type": "quote", "symbol": "AAPL", "bid": 179.95, "ask": 180.00, "ts": 1730330000 }
{ "type": "fill", "order_id": "...", "qty": 10, "price": 179.98, "ts": 1730330002 }

Testing and observability

Synthetic orders in sandbox; venue simulators; chaos testing during off‑hours.
Tracing (OpenTelemetry) across gateway→OMS→router; SLOs for ACK latency and fill notification.
Circuit breakers on venue connectors; auto‑failover to alternate venues.

Common pitfalls and mitigations

Quote storms: symbol throttling, coalescing, and per‑client subscription limits.
Regulatory outages: venue‑specific halts; propagate limit‑up/limit‑down to UI.
Clock skew: NTP tightly; use exchange timestamps for price/lot accounting where possible.
Idempotency gaps: ensure dedupe at gateway and OMS levels.

Interview drill‑downs

How do you ensure best‑execution evidence? Capture NBBO snapshot and router decision.
What if Kafka lags? Backpressure fanout, prioritize hot symbols, degrade analytics.
How to avoid double fills on retry? Idempotent order keys and venue orderId mapping.
How to compute buying power for options spreads? Margin engine with strategy recognition.

Capacity & regulatory readiness

Capacity: assume 1M DAU market hours, 100k peak concurrent; 20k TPS orders burst. Partition OMS by account id; pre‑allocate order ids; ensure venue connectors scale horizontally.
Data retention: WORM storage for audit/Reg‑NMS artifacts; 7‑year retention for trade/ledger per jurisdiction.
SLOs: Order ACK P95 < 200 ms; balance update P95 < 500 ms; quote fanout P95 < 150 ms.

Consistency & correctness

Strong consistency for orders/positions/ledger via single‑writer txns; eventual for portfolio charts.
Idempotency and exactly‑once semantics on order create with constraint indexes; reconcile fills vs. venue daily.

Failure drills

Venue outage: auto‑reroute; if all venues fail, place orders into park queue and inform clients.
Partial ledger failure: circuit‑break trading; reconcile and recover from Kafka with compensating entries.

Evolution

Start with equities cash accounts; add margin, options, and crypto with separate risk engines; move to multi‑region read replicas, with OMS in primary only.

Detailed APIs

POST /v1/orders { account_id, symbol, side, type, qty, limit_price?, tif } -> { id }
GET  /v1/orders/{id}
GET  /v1/quotes?symbols=AAPL,TSLA

Data models (DDL sketch)

CREATE TABLE orders (
  id bigint PRIMARY KEY,
  account_id bigint,
  symbol text,
  side smallint,
  type smallint,
  qty numeric(18,4),
  limit_price numeric(18,4),
  tif smallint,
  state smallint,
  created_at timestamptz
);

Failure drills

OMS db failover → promote replica; halt routing; reconcile from Kafka; resume.
Exchange reject storm → auto‑throttle; switch venues; client messaging.

Test plan

Simulated market opens; PDT rule edge cases; ledger reconciliation fuzzing; venue connector chaos tests.

What Interviewers Look For

Fintech/Trading Systems Skills

Order Management System (OMS)
- Order state machine
- Idempotency
- Risk checks
- Red Flags: No state machine, no idempotency, race conditions
Market Data Processing
- Real-time quote ingestion
- Low-latency delivery
- Quote fanout
- Red Flags: High latency, no real-time, poor delivery
Risk & Compliance
- Pattern Day Trader checks
- Margin calculations
- Regulatory compliance
- Red Flags: No risk checks, compliance issues, regulatory violations

Distributed Systems Skills

Low Latency Design
- Order ACK < 200ms
- Quote delivery < 300ms
- Fill notification < 1s
- Red Flags: High latency, slow operations, poor UX
Consistency Models
- Strong consistency for orders
- Eventual for analytics
- Red Flags: Wrong consistency, no understanding
Event-Driven Architecture
- Kafka for events
- Stream processing
- Red Flags: No events, synchronous processing, bottlenecks

Problem-Solving Approach

Regulatory Compliance
- Reg-NMS/Best-ex
- Audit trails
- Data retention
- Red Flags: No compliance, no audit, regulatory issues
Edge Cases
- Venue outages
- Partial fills
- Clock skew
- Red Flags: Ignoring edge cases, no handling
Trade-off Analysis
- Latency vs consistency
- Cost vs performance
- Red Flags: No trade-offs, dogmatic choices

System Design Skills

Component Design
- OMS
- Market data service
- Risk engine
- Red Flags: Monolithic, unclear boundaries
Security Design
- Authentication/authorization
- PII encryption
- PCI DSS compliance
- Red Flags: No security, insecure, compliance issues
Reliability Design
- Graceful degradation
- Circuit breakers
- Regional redundancy
- Red Flags: No redundancy, no degradation, poor reliability

Communication Skills

Trading System Explanation
- Can explain order flow
- Understands risk/compliance
- Red Flags: No understanding, vague explanations
Latency Explanation
- Can explain optimization strategies
- Understands trade-offs
- Red Flags: No understanding, vague

Meta-Specific Focus

Fintech Expertise
- Trading systems knowledge
- Regulatory understanding
- Key: Show fintech expertise
Low-Latency Systems
- Real-time processing
- Performance optimization
- Key: Demonstrate low-latency expertise
