Introduction

Instagram is a photo and video-sharing social networking service where users can upload, edit, and share content with followers. Designing Instagram requires handling massive scale: billions of users, millions of uploads per day, and petabytes of media storage.

This post provides a detailed walkthrough of designing Instagram, covering key features, scalability challenges, and architectural decisions. This is one of the most common system design interview questions that tests your understanding of distributed systems, media storage, feed generation, and real-time features.

Table of Contents

  1. Problem Statement
  2. Requirements
  3. Capacity Estimation
  4. Core Entities
  5. API
  6. Data Flow
  7. Database Design
  8. High-Level Design
  9. Deep Dive
  10. Summary

Problem Statement

Design Instagram with the following features:

  1. Users can upload photos and videos
  2. Users can follow other users
  3. Users see a feed of photos/videos from users they follow
  4. Users can like and comment on posts
  5. Users can search for photos by tags/usernames
  6. Support for stories (temporary content that expires after 24 hours)

Scale Requirements:

  • 1 billion+ users
  • 500 million+ daily active users
  • 100 million+ photos/videos uploaded per day
  • 23 billion+ photos viewed per day
  • Average photo size: 200KB
  • Average video size: 2MB

Requirements

Functional Requirements

Core Features:

  1. User Management: Registration, authentication, profiles
  2. Media Upload: Upload photos and videos
  3. Feed Generation: Display posts from followed users
  4. Social Graph: Follow/unfollow users
  5. Interactions: Like, comment on posts
  6. Search: Search by username, hashtags, locations
  7. Stories: Temporary content that expires after 24 hours
  8. Notifications: Real-time notifications for likes, comments, follows

Out of Scope:

  • Direct messaging (DM) feature
  • Video streaming (assume simple video playback)
  • Advanced filters and editing
  • Live streaming
  • Reels/IGTV (focus on basic feed)

Non-Functional Requirements

  1. Availability: 99.9% uptime
  2. Reliability: No data loss, all uploads must succeed
  3. Performance:
    • Feed load time: < 200ms
    • Photo upload: < 3 seconds
    • Video upload: < 30 seconds
  4. Scalability: Handle 100M+ uploads per day
  5. Consistency: Eventually consistent is acceptable for feed
  6. Durability: All media must be stored reliably

Capacity Estimation

Traffic Estimates

  • Daily Active Users (DAU): 500 million
  • Daily uploads: 100 million (photos + videos)
  • Read:Write ratio: 100:1 (23B views / 100M uploads)
  • Average user views: 46 photos/videos per day
  • Peak traffic: 3x average = 300M uploads/day peak

Storage Estimates

Photos:

  • 100M photos/day × 200KB = 20TB/day
  • 5 years retention: 20TB × 365 × 5 = 36.5PB

Videos:

  • 20M videos/day × 2MB = 40TB/day
  • 5 years retention: 40TB × 365 × 5 = 73PB

Total Media Storage: ~110PB over 5 years

Metadata Storage:

  • User data: 1B users × 1KB = 1TB
  • Posts metadata: 100M/day × 365 × 5 × 500 bytes = 91TB
  • Social graph: 1B users × 500 followers avg × 8 bytes = 4TB
  • Total metadata: ~100TB

Bandwidth Estimates

  • Upload bandwidth: 20TB/day (photos) + 40TB/day (videos) = 60TB/day = 694MB/s
  • Download bandwidth: 60TB/day × 100 (read:write ratio) = 6PB/day = 69GB/s

Core Entities

User

  • Attributes: user_id, username, email, password_hash, full_name, bio, profile_picture_url
  • Relationships: Follows other users, creates posts, likes/comments on posts

Post

  • Attributes: post_id, user_id, media_type, media_url, thumbnail_url, caption, location, like_count, comment_count, created_at
  • Relationships: Belongs to user, has likes and comments

Follow

  • Attributes: follower_id, followee_id, created_at
  • Relationships: Links users (follower → followee)

Like

  • Attributes: like_id, user_id, post_id, created_at
  • Relationships: Links user to post

Comment

  • Attributes: comment_id, post_id, user_id, text, created_at
  • Relationships: Belongs to post and user

Story

  • Attributes: story_id, user_id, media_url, media_type, expires_at, created_at
  • Relationships: Belongs to user, expires after 24 hours

API

1. Upload Photo/Video

POST /api/v1/media/upload
Parameters:
  - file: photo/video file
  - user_id: user ID
  - caption: optional text caption
  - location: optional location data
Response:
  - media_id: unique media identifier
  - upload_url: URL for direct upload

2. Get User Feed

GET /api/v1/feed
Parameters:
  - user_id: user ID
  - max_id: pagination cursor (optional)
  - count: number of posts to return (default: 20)
Response:
  - posts: array of post objects
  - next_max_id: cursor for next page

3. Follow User

POST /api/v1/follow
Parameters:
  - user_id: current user ID
  - follow_user_id: user to follow
Response:
  - success: boolean

4. Like Post

POST /api/v1/posts/{post_id}/like
Parameters:
  - user_id: user ID
  - post_id: post ID
Response:
  - like_count: updated like count

5. Comment on Post

POST /api/v1/posts/{post_id}/comments
Parameters:
  - user_id: user ID
  - post_id: post ID
  - text: comment text
Response:
  - comment_id: unique comment identifier

6. Get User Stories

GET /api/v1/stories/{user_id}
Parameters:
  - user_id: user ID
Response:
  - stories: array of story objects

Data Flow

Upload Flow

  1. Client uploads media file → Load Balancer
  2. Load Balancer → API Gateway
  3. API Gateway → Upload Service
  4. Upload Service validates file and generates media ID
  5. Upload Service → Object Storage (S3) for media storage
  6. Upload Service → Database for metadata storage
  7. Upload Service → Message Queue (for async processing)
  8. Message Queue → Thumbnail Service (async)
  9. Upload Service → Cache invalidation (user feed)
  10. Response returned to client

Feed Generation Flow

  1. Client requests feed → Load Balancer
  2. Load Balancer → API Gateway
  3. API Gateway → Feed Service
  4. Feed Service checks Redis cache
  5. If cache miss:
    • Fetch followed users from Social Graph Service
    • Fetch posts from Database (or cache)
    • Merge and sort posts
    • Cache result in Redis
  6. Return feed to client

Like/Comment Flow

  1. Client submits like/comment → API Gateway
  2. API Gateway → Interaction Service
  3. Interaction Service → Database (write)
  4. Interaction Service → Cache invalidation (post cache)
  5. Interaction Service → Message Queue (for notifications)
  6. Message Queue → Notification Service
  7. Response returned to client

Database Design

Schema Design

Users Table:

CREATE TABLE users (
    user_id BIGINT PRIMARY KEY,
    username VARCHAR(255) UNIQUE NOT NULL,
    email VARCHAR(255) UNIQUE NOT NULL,
    password_hash VARCHAR(255) NOT NULL,
    full_name VARCHAR(255),
    bio TEXT,
    profile_picture_url VARCHAR(512),
    created_at TIMESTAMP,
    updated_at TIMESTAMP,
    INDEX idx_username (username),
    INDEX idx_email (email)
);

Posts Table:

CREATE TABLE posts (
    post_id BIGINT PRIMARY KEY,
    user_id BIGINT NOT NULL,
    media_type ENUM('photo', 'video') NOT NULL,
    media_url VARCHAR(512) NOT NULL,
    thumbnail_url VARCHAR(512),
    caption TEXT,
    location VARCHAR(255),
    like_count INT DEFAULT 0,
    comment_count INT DEFAULT 0,
    created_at TIMESTAMP,
    INDEX idx_user_id (user_id),
    INDEX idx_created_at (created_at),
    FOREIGN KEY (user_id) REFERENCES users(user_id)
);

Follows Table:

CREATE TABLE follows (
    follower_id BIGINT NOT NULL,
    followee_id BIGINT NOT NULL,
    created_at TIMESTAMP,
    PRIMARY KEY (follower_id, followee_id),
    INDEX idx_follower (follower_id),
    INDEX idx_followee (followee_id),
    FOREIGN KEY (follower_id) REFERENCES users(user_id),
    FOREIGN KEY (followee_id) REFERENCES users(user_id)
);

Likes Table:

CREATE TABLE likes (
    like_id BIGINT PRIMARY KEY,
    user_id BIGINT NOT NULL,
    post_id BIGINT NOT NULL,
    created_at TIMESTAMP,
    UNIQUE KEY unique_like (user_id, post_id),
    INDEX idx_post_id (post_id),
    INDEX idx_user_id (user_id),
    FOREIGN KEY (user_id) REFERENCES users(user_id),
    FOREIGN KEY (post_id) REFERENCES posts(post_id)
);

Comments Table:

CREATE TABLE comments (
    comment_id BIGINT PRIMARY KEY,
    post_id BIGINT NOT NULL,
    user_id BIGINT NOT NULL,
    text TEXT NOT NULL,
    created_at TIMESTAMP,
    INDEX idx_post_id (post_id),
    FOREIGN KEY (post_id) REFERENCES posts(post_id),
    FOREIGN KEY (user_id) REFERENCES users(user_id)
);

Stories Table:

CREATE TABLE stories (
    story_id BIGINT PRIMARY KEY,
    user_id BIGINT NOT NULL,
    media_url VARCHAR(512) NOT NULL,
    media_type ENUM('photo', 'video') NOT NULL,
    expires_at TIMESTAMP NOT NULL,
    created_at TIMESTAMP,
    INDEX idx_user_id (user_id),
    INDEX idx_expires_at (expires_at),
    FOREIGN KEY (user_id) REFERENCES users(user_id)
);

Database Sharding Strategy

Shard by User ID:

  • Use consistent hashing to distribute users across shards
  • User data, posts, and follows stored on same shard for locality
  • Enables efficient feed generation for a user’s own posts

Challenges:

  • Cross-shard queries for feed generation (posts from multiple users)
  • Need to aggregate data from multiple shards

High-Level Design

┌─────────────┐
│   Client    │
│  (Mobile/   │
│    Web)     │
└──────┬──────┘
       │
       ▼
┌─────────────────────────────────────────┐
│         Load Balancer                   │
└──────┬──────────────────┬───────────────┘
       │                  │
       ▼                  ▼
┌──────────────┐   ┌──────────────┐
│  API Gateway │   │  API Gateway │
└──────┬───────┘   └──────┬───────┘
       │                  │
       ├──────────────────┼──────────────────┐
       │                  │                  │
       ▼                  ▼                  ▼
┌──────────────┐  ┌──────────────┐  ┌──────────────┐
│ Upload       │  │ Feed        │  │ Social Graph │
│ Service      │  │ Service     │  │ Service      │
└──────┬───────┘  └──────┬───────┘  └──────┬───────┘
       │                 │                 │
       ▼                 ▼                 ▼
┌──────────────┐  ┌──────────────┐  ┌──────────────┐
│ Object       │  │ Cache        │  │ Database     │
│ Storage      │  │ (Redis)      │  │ (Sharded)    │
│ (S3/CDN)     │  └──────────────┘  └──────────────┘
└──────────────┘

Deep Dive

Component Design

1. Upload Service

Flow:

  1. Client uploads media file to Upload Service
  2. Upload Service validates file (size, format)
  3. Generate unique media ID
  4. Upload to Object Storage (S3)
  5. Generate thumbnail for videos
  6. Store metadata in database
  7. Invalidate cache for user’s feed
  8. Return success response

Optimizations:

  • Resumable uploads: For large videos, support chunked uploads
  • Async processing: Thumbnail generation and metadata extraction done asynchronously
  • CDN integration: Upload directly to CDN edge locations

2. Feed Service

Feed Generation Approaches:

Approach 1: Pull Model (Fan-out on Read)

  • When user requests feed, fetch posts from all followed users
  • Aggregate and sort posts
  • Pros: Simple, real-time data
  • Cons: Slow for users with many followees, high database load

Approach 2: Push Model (Fan-out on Write)

  • When user posts, push to all followers’ feed caches
  • Pros: Fast feed retrieval
  • Cons: High write load, storage overhead

Approach 3: Hybrid Approach (Recommended)

  • Push model for users with < 1000 followers
  • Pull model for users with > 1000 followers (celebrities)
  • Use Redis sorted sets for feed storage

Feed Generation Flow:

  1. Check Redis cache for user feed
  2. If cache miss:
    • Fetch recent posts from followed users
    • Merge and sort by timestamp
    • Cache result in Redis
  3. Return feed to user

Redis Data Structure:

Key: feed:{user_id}
Type: Sorted Set
Score: timestamp
Value: post_id
TTL: 7 days

3. Social Graph Service

Stores follow relationships:

  • Use graph database (Neo4j) or relational DB with optimized indexes
  • Cache frequently accessed relationships in Redis

Redis Cache:

Key: followers:{user_id}
Type: Set
Value: follower user_ids
TTL: 1 hour

Key: following:{user_id}
Type: Set
Value: followee user_ids
TTL: 1 hour

4. Search Service

Features:

  • Search by username
  • Search by hashtags
  • Search by location

Implementation:

  • Use Elasticsearch for full-text search
  • Index usernames, hashtags, captions, locations
  • Real-time indexing via message queue

5. Stories Service

Features:

  • Stories expire after 24 hours
  • Background job removes expired stories
  • Stories appear at top of feed

Implementation:

  • Store stories in database with expires_at timestamp
  • Background cron job deletes expired stories
  • Cache active stories in Redis with TTL

Detailed Design

Media Storage Architecture

Object Storage (S3):

  • Store original photos and videos
  • Use multiple availability zones for redundancy
  • Lifecycle policies for old content

CDN (CloudFront):

  • Cache frequently accessed media
  • Serve media from edge locations
  • Reduce origin server load

Storage Tiers:

  1. Hot storage: Recent posts (last 30 days) - SSD
  2. Warm storage: Older posts (30 days - 1 year) - Standard
  3. Cold storage: Archive (1+ years) - Glacier

Caching Strategy

Multi-level Caching:

L1: Application Cache (In-memory)

  • Cache user profiles, recent posts
  • TTL: 5 minutes

L2: Redis Cache

  • Feed data, social graph, trending posts
  • TTL: 1 hour for feeds, 24 hours for profiles

L3: CDN Cache

  • Media files, static content
  • TTL: 7 days

Cache Invalidation:

  • On post upload: Invalidate user’s feed cache
  • On like/comment: Invalidate post cache
  • On follow/unfollow: Invalidate feed cache

Load Balancing

Strategy:

  • Layer 4 (NLB): For media uploads (high bandwidth)
  • Layer 7 (ALB): For API requests (routing based on path)

Load Balancer Features:

  • Health checks
  • SSL termination
  • Request routing
  • Rate limiting

Database Replication

Master-Slave Replication:

  • Master handles writes
  • Slaves handle reads
  • Automatic failover

Read Replicas:

  • Distribute read load across multiple replicas
  • Geographic distribution for low latency

Message Queue

Use Cases:

  1. Async processing: Thumbnail generation, metadata extraction
  2. Feed updates: Fan-out to followers
  3. Notifications: Like, comment, follow notifications
  4. Search indexing: Update search index

Technology: Apache Kafka or AWS SQS

Scalability Considerations

Horizontal Scaling

Stateless Services:

  • Upload Service, Feed Service, API Gateway
  • Scale based on CPU/memory metrics

Database Scaling:

  • Shard by user_id
  • Use consistent hashing
  • Replicate shards for availability

Data Partitioning

Sharding Strategy:

  • By User ID: User data, posts, follows on same shard
  • By Post ID: For global post lookups
  • By Location: For location-based queries

Handling Hot Users

Problem: Celebrities with millions of followers

Solutions:

  1. Separate feed generation: Use pull model for hot users
  2. Dedicated infrastructure: Separate servers for hot users
  3. Rate limiting: Prevent abuse
  4. Caching: Aggressive caching for hot content

Security Considerations

  1. Authentication: JWT tokens, OAuth 2.0
  2. Authorization: Role-based access control
  3. Media validation: File type, size, content scanning
  4. Rate limiting: Prevent abuse
  5. DDoS protection: CloudFlare, AWS Shield
  6. Data encryption: Encrypt data at rest and in transit
  7. Privacy: User privacy settings, content visibility controls

Monitoring & Observability

Key Metrics:

  • Upload success rate
  • Feed generation latency
  • API response times
  • Cache hit rates
  • Database query performance
  • CDN bandwidth usage

Tools:

  • Prometheus + Grafana for metrics
  • ELK stack for logging
  • Distributed tracing (Jaeger/Zipkin)

Trade-offs and Optimizations

Trade-offs

  1. Consistency vs Availability
    • Choose eventual consistency for feeds (better availability)
    • Strong consistency for critical operations (likes, follows)
  2. Storage vs Compute
    • Pre-compute feeds (more storage, faster reads)
    • Compute on-demand (less storage, slower reads)
    • Hybrid approach balances both
  3. Latency vs Freshness
    • Cache feeds (lower latency, stale data)
    • Real-time updates (higher latency, fresh data)
    • Use cache with short TTL

Optimizations

  1. Image Optimization
    • Multiple resolutions (thumbnail, medium, full)
    • WebP format for better compression
    • Lazy loading
  2. Video Optimization
    • Multiple bitrates for adaptive streaming
    • H.264/H.265 encoding
    • Progressive download
  3. Database Optimization
    • Indexes on frequently queried fields
    • Connection pooling
    • Query optimization
  4. Caching Optimization
    • Cache warming for popular content
    • Cache aside pattern
    • Write-through for critical data

What Interviewers Look For

Distributed Systems Skills

  1. Scalability Design
    • Horizontal scaling strategies
    • Sharding and partitioning
    • Load balancing approaches
    • Red Flags: Vertical scaling only, no sharding strategy, single points of failure
  2. Media Storage Architecture
    • Object storage design (S3-like)
    • CDN integration
    • Efficient media delivery
    • Red Flags: Database storage for media, no CDN, inefficient delivery
  3. Feed Generation Strategy
    • Push vs pull trade-offs
    • Hybrid approach understanding
    • Timeline caching
    • Red Flags: Only push or only pull, no hybrid, no caching

Problem-Solving Approach

  1. Scale Thinking
    • Billions of users consideration
    • Petabytes of storage
    • Millions of requests per second
    • Red Flags: Designing for small scale, ignoring scale challenges
  2. Trade-off Analysis
    • Consistency vs availability
    • Latency vs freshness
    • Storage cost vs performance
    • Red Flags: No trade-off discussion, dogmatic choices
  3. Edge Cases
    • Celebrity users (millions of followers)
    • Viral content
    • Storage failures
    • Red Flags: Ignoring edge cases, no failure handling

System Design Skills

  1. Component Design
    • Clear service boundaries
    • Proper API design
    • Data flow understanding
    • Red Flags: Monolithic design, unclear boundaries
  2. Caching Strategy
    • Multi-level caching
    • Cache invalidation
    • Cache warming
    • Red Flags: No caching, poor invalidation, cache stampede
  3. Database Design
    • Proper sharding strategy
    • Index design
    • Read replicas
    • Red Flags: No sharding, missing indexes, no read scaling

Communication Skills

  1. Clear Architecture Explanation
    • Can explain design clearly
    • Justifies decisions
    • Discusses alternatives
    • Red Flags: Unclear explanations, no justification
  2. Capacity Estimation
    • Realistic estimates
    • Proper calculations
    • Resource planning
    • Red Flags: Unrealistic estimates, no calculations

Meta-Specific Focus

  1. Feed Generation Patterns
    • Understanding of push/pull/hybrid
    • Timeline caching knowledge
    • Key: Show understanding of Meta’s patterns
  2. Scale-First Thinking
    • Design for billions from start
    • Global distribution
    • Key: Demonstrate scale awareness

Summary

Designing Instagram requires handling:

  1. Massive Scale: Billions of users, petabytes of media
  2. High Read:Write Ratio: 100:1 read to write ratio
  3. Real-time Features: Feed updates, notifications
  4. Media Storage: Efficient storage and delivery of photos/videos
  5. Social Graph: Efficient follow/unfollow operations
  6. Feed Generation: Fast feed retrieval with hybrid push/pull model

Key Architectural Decisions:

  • Object storage (S3) + CDN for media
  • Sharded databases for scalability
  • Redis for caching and feed storage
  • Hybrid feed generation (push for normal users, pull for celebrities)
  • Message queues for async processing
  • Multi-level caching strategy

This design can handle Instagram’s scale while maintaining low latency and high availability.
