Introduction

A configuration service is a centralized system that manages and distributes configuration data to multiple microservices. It provides a single source of truth for application settings, feature flags, environment variables, and runtime configurations. When combined with LRU (Least Recently Used) caching, it can handle millions of configuration reads per second with sub-millisecond latency.

This post provides a detailed walkthrough of designing a configuration service with LRU cache, covering configuration storage, caching strategies, change propagation, versioning, multi-service distribution, and handling high read throughput. This is a common system design interview question that tests your understanding of distributed systems, caching algorithms, pub/sub patterns, and configuration management.

Table of Contents

  1. Problem Statement
  2. Requirements
  3. Capacity Estimation
  4. Core Entities
  5. API
  6. Data Flow
  7. Database Design
  8. High-Level Design
  9. Deep Dive
  10. Summary

Problem Statement

Design a centralized configuration service with LRU cache that distributes configuration data to multiple microservices:

  1. Store configuration data (key-value pairs, JSON, YAML)
  2. Support multiple environments (dev, staging, prod)
  3. Support multiple services/applications
  4. Provide fast read access with LRU cache
  5. Support configuration updates and versioning
  6. Propagate configuration changes to all services
  7. Support configuration rollback
  8. Handle high read throughput (millions of reads per second)
  9. Support configuration encryption for sensitive data
  10. Provide configuration validation and schema enforcement

Scale Requirements:

  • 1000+ microservices
  • 10 million+ configuration keys
  • 1 billion+ configuration reads per day
  • Peak: 100,000 reads per second
  • Average latency: < 1ms (with cache)
  • Cache hit rate: > 95%
  • Configuration updates: 10,000 per day
  • Must support real-time change propagation

Requirements

Functional Requirements

Core Features:

  1. Configuration Storage: Store key-value configurations
  2. Multi-Environment: Support dev, staging, prod environments
  3. Multi-Service: Support multiple services/applications
  4. Fast Reads: LRU cache for sub-millisecond reads
  5. Configuration Updates: Update configurations with versioning
  6. Change Propagation: Notify services of configuration changes
  7. Configuration Rollback: Rollback to previous versions
  8. Configuration Validation: Validate configuration schemas
  9. Encryption: Encrypt sensitive configuration values
  10. Configuration Search: Search configurations by key, service, environment

Out of Scope:

  • Configuration UI/Admin panel (focus on API)
  • User authentication (assume existing auth system)
  • Configuration templates
  • Configuration inheritance
  • Mobile app (focus on service-to-service communication)

Non-Functional Requirements

  1. Availability: 99.99% uptime
  2. Reliability: No configuration loss, consistent reads
  3. Performance:
    • Cache read: < 1ms (p99)
    • Database read: < 10ms (p99)
    • Configuration update: < 100ms
    • Change propagation: < 1 second
  4. Scalability: Handle 100K+ reads per second
  5. Consistency: Strong consistency for writes, eventual consistency for reads
  6. Cache Hit Rate: > 95% cache hit rate
  7. Durability: All configurations persisted to database

Capacity Estimation

Traffic Estimates

  • Total Services: 1,000
  • Configuration Keys: 10 million
  • Configuration Reads per Day: 1 billion
  • Peak Read Rate: 100,000 per second
  • Normal Read Rate: 10,000 per second
  • Configuration Updates per Day: 10,000
  • Average Reads per Service: 1,000 per second
  • Cache Hit Rate: 95%

Storage Estimates

Configuration Data:

  • 10M keys × 1KB average = 10GB
  • Configuration metadata: 10M × 200 bytes = 2GB
  • Version history: 10K updates/day × 365 days × 1KB = 3.65GB/year
  • 5-year retention: ~18GB

Cache Data:

  • LRU cache: 1M hot keys × 1KB = 1GB per instance
  • 10 cache instances: ~10GB

Total Storage: ~30GB

Bandwidth Estimates

Normal Traffic:

  • 10,000 reads/sec × 1KB = 10MB/s = 80Mbps
  • Cache hits (95%): 9,500/sec × 1KB = 9.5MB/s
  • Cache misses (5%): 500/sec × 1KB = 0.5MB/s

Peak Traffic:

  • 100,000 reads/sec × 1KB = 100MB/s = 800Mbps

Change Propagation:

  • 10,000 updates/day × 1KB × 1,000 services = 10GB/day = ~115KB/s = ~1Mbps

Total Peak: ~800Mbps

Core Entities

Configuration

  • config_id (UUID)
  • service_name (VARCHAR)
  • environment (dev, staging, prod)
  • config_key (VARCHAR)
  • config_value (TEXT/JSON)
  • value_type (string, number, boolean, json, yaml)
  • is_encrypted (BOOLEAN)
  • version (INT)
  • created_at (TIMESTAMP)
  • updated_at (TIMESTAMP)
  • created_by (user_id)

Configuration Version

  • version_id (UUID)
  • config_id (UUID)
  • version (INT)
  • config_value (TEXT/JSON)
  • change_description (TEXT)
  • created_at (TIMESTAMP)
  • created_by (user_id)

Service Subscription

  • subscription_id (UUID)
  • service_name (VARCHAR)
  • environment (VARCHAR)
  • subscribed_keys (JSON array)
  • webhook_url (VARCHAR, optional)
  • last_notified_at (TIMESTAMP)
  • created_at (TIMESTAMP)
  • updated_at (TIMESTAMP)

Configuration Schema

  • schema_id (UUID)
  • service_name (VARCHAR)
  • config_key (VARCHAR)
  • schema_definition (JSON)
  • validation_rules (JSON)
  • created_at (TIMESTAMP)
  • updated_at (TIMESTAMP)

API

1. Get Configuration

GET /api/v1/config/{service_name}/{environment}/{config_key}
Response:
{
  "service_name": "user-service",
  "environment": "prod",
  "config_key": "database.url",
  "config_value": "postgresql://db.example.com:5432/users",
  "value_type": "string",
  "version": 5,
  "updated_at": "2025-11-13T10:00:00Z"
}

2. Get Multiple Configurations

POST /api/v1/config/batch
Request:
{
  "service_name": "user-service",
  "environment": "prod",
  "config_keys": ["database.url", "cache.ttl", "feature.flag"]
}

Response:
{
  "configs": [
    {
      "config_key": "database.url",
      "config_value": "postgresql://db.example.com:5432/users",
      "version": 5
    },
    {
      "config_key": "cache.ttl",
      "config_value": "3600",
      "version": 3
    },
    {
      "config_key": "feature.flag",
      "config_value": "true",
      "version": 2
    }
  ]
}

3. Set Configuration

PUT /api/v1/config/{service_name}/{environment}/{config_key}
Request:
{
  "config_value": "postgresql://db.example.com:5432/users",
  "value_type": "string",
  "change_description": "Updated database URL",
  "encrypt": false
}

Response:
{
  "config_id": "uuid",
  "service_name": "user-service",
  "environment": "prod",
  "config_key": "database.url",
  "config_value": "postgresql://db.example.com:5432/users",
  "version": 6,
  "updated_at": "2025-11-13T10:05:00Z"
}

4. Delete Configuration

DELETE /api/v1/config/{service_name}/{environment}/{config_key}
Response:
{
  "success": true,
  "message": "Configuration deleted"
}

5. Get Configuration History

GET /api/v1/config/{service_name}/{environment}/{config_key}/history?limit=10
Response:
{
  "config_key": "database.url",
  "versions": [
    {
      "version": 6,
      "config_value": "postgresql://db.example.com:5432/users",
      "change_description": "Updated database URL",
      "created_at": "2025-11-13T10:05:00Z",
      "created_by": "user123"
    },
    {
      "version": 5,
      "config_value": "postgresql://db.old.com:5432/users",
      "change_description": "Initial configuration",
      "created_at": "2025-11-10T08:00:00Z",
      "created_by": "user123"
    }
  ]
}

6. Rollback Configuration

POST /api/v1/config/{service_name}/{environment}/{config_key}/rollback
Request:
{
  "target_version": 5
}

Response:
{
  "config_id": "uuid",
  "version": 7,
  "previous_version": 6,
  "rolled_back_to": 5,
  "updated_at": "2025-11-13T10:10:00Z"
}

7. Subscribe to Configuration Changes

POST /api/v1/config/subscribe
Request:
{
  "service_name": "user-service",
  "environment": "prod",
  "config_keys": ["database.url", "cache.ttl"],
  "webhook_url": "https://user-service.example.com/config/webhook"
}

Response:
{
  "subscription_id": "uuid",
  "service_name": "user-service",
  "subscribed_keys": ["database.url", "cache.ttl"],
  "status": "active"
}

Data Flow

Configuration Read Flow (Cache Hit)

  1. Service Requests Config:
    • Microservice requests configuration
    • Client SDK sends request to API Gateway
    • API Gateway routes to Configuration Service
  2. Cache Lookup:
    • Configuration Service:
      • Constructs cache key: {service_name}:{environment}:{config_key}
      • Checks LRU Cache
      • Cache hit: Returns cached value immediately
  3. Response:
    • Configuration Service returns configuration
    • Client SDK caches locally (optional)
    • Microservice uses configuration

Configuration Read Flow (Cache Miss)

  1. Service Requests Config:
    • Microservice requests configuration
    • Client SDK sends request to API Gateway
    • API Gateway routes to Configuration Service
  2. Cache Lookup:
    • Configuration Service checks LRU Cache
    • Cache miss: Proceeds to database
  3. Database Query:
    • Configuration Service queries Database
    • Retrieves configuration by service, environment, key
  4. Cache Update:
    • Configuration Service:
      • Stores configuration in LRU Cache
      • Evicts least recently used entry if cache full
      • Returns configuration
  5. Response:
    • Configuration Service returns configuration
    • Client SDK caches locally (optional)
    • Microservice uses configuration

Configuration Update Flow

  1. Admin Updates Config:
    • Admin updates configuration via API
    • API Gateway routes to Configuration Service
  2. Validation:
    • Configuration Service:
      • Validates configuration schema
      • Checks permissions
      • Encrypts value if needed
  3. Database Update:
    • Configuration Service:
      • Updates configuration in Database
      • Creates version record
      • Increments version number
      • Updates timestamp
  4. Cache Invalidation:
    • Configuration Service:
      • Invalidates cache entry
      • Removes from LRU Cache
  5. Change Propagation:
    • Configuration Service:
      • Publishes change event to Message Queue
      • Notification Service notifies subscribed services
      • Services update local cache
  6. Response:
    • Configuration Service returns updated configuration

Configuration Change Notification Flow

  1. Configuration Updated:
    • Configuration updated in database
    • Change event published to Message Queue
  2. Notification Processing:
    • Notification Service:
      • Gets all service subscriptions for changed key
      • Filters by service and environment
      • Creates notification jobs
  3. Notification Delivery:
    • Notification Workers:
      • Send webhook notifications to services
      • Or publish to service-specific message queues
      • Handle failures with retry logic
  4. Service Update:
    • Microservice receives notification
    • Invalidates local cache
    • Fetches new configuration
    • Updates application state

Database Design

Schema Design

Configurations Table:

CREATE TABLE configurations (
    config_id UUID PRIMARY KEY,
    service_name VARCHAR(100) NOT NULL,
    environment VARCHAR(50) NOT NULL,
    config_key VARCHAR(500) NOT NULL,
    config_value TEXT NOT NULL,
    value_type VARCHAR(50) DEFAULT 'string',
    is_encrypted BOOLEAN DEFAULT FALSE,
    version INT NOT NULL DEFAULT 1,
    created_at TIMESTAMP DEFAULT NOW(),
    updated_at TIMESTAMP DEFAULT NOW(),
    created_by VARCHAR(100),
    INDEX idx_service_env (service_name, environment),
    INDEX idx_key (config_key),
    INDEX idx_service_env_key (service_name, environment, config_key),
    UNIQUE KEY uk_service_env_key (service_name, environment, config_key)
);

Configuration Versions Table:

CREATE TABLE configuration_versions (
    version_id UUID PRIMARY KEY,
    config_id UUID NOT NULL,
    version INT NOT NULL,
    config_value TEXT NOT NULL,
    change_description TEXT,
    created_at TIMESTAMP DEFAULT NOW(),
    created_by VARCHAR(100),
    INDEX idx_config_id (config_id),
    INDEX idx_config_version (config_id, version),
    FOREIGN KEY (config_id) REFERENCES configurations(config_id)
);

Service Subscriptions Table:

CREATE TABLE service_subscriptions (
    subscription_id UUID PRIMARY KEY,
    service_name VARCHAR(100) NOT NULL,
    environment VARCHAR(50) NOT NULL,
    subscribed_keys JSON NOT NULL,
    webhook_url VARCHAR(1000),
    last_notified_at TIMESTAMP NULL,
    created_at TIMESTAMP DEFAULT NOW(),
    updated_at TIMESTAMP DEFAULT NOW(),
    INDEX idx_service_env (service_name, environment),
    INDEX idx_webhook (webhook_url)
);

Configuration Schemas Table:

CREATE TABLE configuration_schemas (
    schema_id UUID PRIMARY KEY,
    service_name VARCHAR(100) NOT NULL,
    config_key VARCHAR(500) NOT NULL,
    schema_definition JSON NOT NULL,
    validation_rules JSON,
    created_at TIMESTAMP DEFAULT NOW(),
    updated_at TIMESTAMP DEFAULT NOW(),
    INDEX idx_service_key (service_name, config_key),
    UNIQUE KEY uk_service_key (service_name, config_key)
);

Database Sharding Strategy

Configurations Table Sharding:

  • Shard by service_name using consistent hashing
  • 100 shards: shard_id = hash(service_name) % 100
  • All configurations for a service in same shard
  • Enables efficient service-specific queries

Shard Key Selection:

  • service_name ensures all configs for a service are in same shard
  • Enables efficient queries for service configurations
  • Prevents cross-shard queries for single service

Replication:

  • Each shard replicated 3x for high availability
  • Master-replica setup for read scaling
  • Writes go to master, reads can go to replicas

High-Level Design

┌─────────────┐
│ Microservice│
│   (Client)  │
└──────┬──────┘
       │
       │ HTTP/GRPC
       │
┌──────▼──────────────────────────────────────────────┐
│        API Gateway / Load Balancer                   │
│        - Rate Limiting                               │
│        - Request Routing                             │
└──────┬──────────────────────────────────────────────┘
       │
       │
┌──────▼──────────────────────────────────────────────┐
│         Configuration Service                         │
│  ┌──────────┐  ┌──────────┐  ┌──────────┐          │
│  │ Config   │  │ Config   │  │ Config   │          │
│  │ Reader   │  │ Writer   │  │ Validator│          │
│  └──────────┘  └──────────┘  └──────────┘          │
└──────┬──────────────────────────────────────────────┘
       │
       │
┌──────▼──────────────────────────────────────────────┐
│         LRU Cache Layer (In-Memory)                 │
│  ┌──────────┐  ┌──────────┐  ┌──────────┐          │
│  │ Cache    │  │ Cache    │  │ Cache    │          │
│  │ Instance │  │ Instance │  │ Instance │          │
│  │ 1        │  │ 2        │  │ N        │          │
│  └──────────┘  └──────────┘  └──────────┘          │
│  - Capacity: 1M keys per instance                   │
│  - Eviction: LRU algorithm                          │
│  - TTL: None (invalidate on update)                  │
└──────┬──────────────────────────────────────────────┘
       │
       │ Cache Miss
       │
┌──────▼──────────────────────────────────────────────┐
│         Database Cluster (Sharded)                   │
│  ┌──────────┐  ┌──────────┐  ┌──────────┐          │
│  │ Shard 0   │  │ Shard 1   │  │ Shard N   │          │
│  │ Configs   │  │ Configs   │  │ Configs   │          │
│  └──────────┘  └──────────┘  └──────────┘          │
└──────────────────────────────────────────────────────┘

┌──────────────────────────────────────────────────────┐
│              Message Queue (Kafka)                    │
│              - Configuration change events            │
│              - Notification jobs                       │
└──────┬───────────────────────────────────────────────┘
       │
       │
┌──────▼───────────────────────────────────────────────┐
│         Notification Service                          │
│         - Process change events                       │
│         - Notify subscribed services                 │
│         - Webhook delivery                           │
└──────────────────────────────────────────────────────┘

┌──────────────────────────────────────────────────────┐
│         Encryption Service                            │
│         - Encrypt sensitive values                    │
│         - Decrypt on read                             │
└──────────────────────────────────────────────────────┘

Deep Dive

Component Design

1. LRU Cache Implementation

Responsibilities:

  • Store frequently accessed configurations
  • Evict least recently used entries
  • Provide sub-millisecond read access
  • Handle cache invalidation

Key Design Decisions:

  • In-Memory Cache: Fast access, limited capacity
  • LRU Eviction: Evict least recently used when full
  • No TTL: Invalidate on update instead
  • Distributed Cache: Multiple cache instances
  • Cache Key Format: {service_name}:{environment}:{config_key}

Implementation:

from collections import OrderedDict

class LRUCache:
    def __init__(self, capacity=1000000):
        self.capacity = capacity
        self.cache = OrderedDict()
        self.lock = threading.Lock()

    def get(self, key):
        with self.lock:
            if key not in self.cache:
                return None

            # Move to end (most recently used)
            self.cache.move_to_end(key)
            return self.cache[key]

    def put(self, key, value):
        with self.lock:
            if key in self.cache:
                # Update existing
                self.cache[key] = value
                self.cache.move_to_end(key)
            else:
                # Add new
                if len(self.cache) >= self.capacity:
                    # Evict least recently used (first item)
                    self.cache.popitem(last=False)

                self.cache[key] = value

    def delete(self, key):
        with self.lock:
            if key in self.cache:
                del self.cache[key]

    def clear(self):
        with self.lock:
            self.cache.clear()

    def size(self):
        return len(self.cache)

class ConfigurationCache:
    def __init__(self):
        self.lru_cache = LRUCache(capacity=1000000)
        self.cache_stats = {
            'hits': 0,
            'misses': 0
        }

    def get_config(self, service_name, environment, config_key):
        cache_key = f"{service_name}:{environment}:{config_key}"

        # Try cache
        value = self.lru_cache.get(cache_key)
        if value:
            self.cache_stats['hits'] += 1
            return value

        # Cache miss
        self.cache_stats['misses'] += 1
        return None

    def set_config(self, service_name, environment, config_key, config_value):
        cache_key = f"{service_name}:{environment}:{config_key}"
        self.lru_cache.put(cache_key, config_value)

    def invalidate_config(self, service_name, environment, config_key):
        cache_key = f"{service_name}:{environment}:{config_key}"
        self.lru_cache.delete(cache_key)

    def get_cache_stats(self):
        total = self.cache_stats['hits'] + self.cache_stats['misses']
        hit_rate = (self.cache_stats['hits'] / total * 100) if total > 0 else 0
        return {
            'hits': self.cache_stats['hits'],
            'misses': self.cache_stats['misses'],
            'hit_rate': hit_rate,
            'cache_size': self.lru_cache.size()
        }

2. Configuration Service

Responsibilities:

  • Handle configuration reads and writes
  • Manage cache
  • Validate configurations
  • Handle encryption

Key Design Decisions:

  • Cache-Aside Pattern: Check cache first, then database
  • Write-Through: Update cache on write
  • Cache Invalidation: Invalidate on update
  • Batch Reads: Support batch configuration reads

Implementation:

class ConfigurationService:
    def __init__(self):
        self.cache = ConfigurationCache()
        self.db = Database()
        self.encryption_service = EncryptionService()
        self.validator = ConfigurationValidator()

    def get_config(self, service_name, environment, config_key):
        # Try cache first
        cached = self.cache.get_config(service_name, environment, config_key)
        if cached:
            return cached

        # Cache miss - query database
        config = self.db.get_configuration(
            service_name=service_name,
            environment=environment,
            config_key=config_key
        )

        if not config:
            return None

        # Decrypt if needed
        if config.is_encrypted:
            config.config_value = self.encryption_service.decrypt(config.config_value)

        # Store in cache
        self.cache.set_config(
            service_name, environment, config_key, config
        )

        return config

    def set_config(self, service_name, environment, config_key, config_value,
                   encrypt=False, change_description=None):
        # Validate configuration
        if not self.validator.validate(service_name, config_key, config_value):
            raise ValidationError("Invalid configuration value")

        # Encrypt if needed
        if encrypt:
            config_value = self.encryption_service.encrypt(config_value)

        # Get current version
        current = self.get_config(service_name, environment, config_key)
        new_version = (current.version + 1) if current else 1

        # Update database
        config = self.db.update_configuration(
            service_name=service_name,
            environment=environment,
            config_key=config_key,
            config_value=config_value,
            version=new_version,
            is_encrypted=encrypt,
            change_description=change_description
        )

        # Create version record
        self.db.create_version(
            config_id=config.config_id,
            version=new_version,
            config_value=config_value,
            change_description=change_description
        )

        # Invalidate cache
        self.cache.invalidate_config(service_name, environment, config_key)

        # Publish change event
        self.publish_change_event(config)

        return config

    def batch_get_config(self, service_name, environment, config_keys):
        results = {}
        cache_misses = []

        # Try cache for all keys
        for key in config_keys:
            cached = self.cache.get_config(service_name, environment, key)
            if cached:
                results[key] = cached
            else:
                cache_misses.append(key)

        # Query database for cache misses
        if cache_misses:
            db_configs = self.db.batch_get_configurations(
                service_name=service_name,
                environment=environment,
                config_keys=cache_misses
            )

            for config in db_configs:
                # Decrypt if needed
                if config.is_encrypted:
                    config.config_value = self.encryption_service.decrypt(
                        config.config_value
                    )

                # Store in cache
                self.cache.set_config(
                    service_name, environment, config.config_key, config
                )

                results[config.config_key] = config

        return results

    def publish_change_event(self, config):
        event = {
            'service_name': config.service_name,
            'environment': config.environment,
            'config_key': config.config_key,
            'version': config.version,
            'updated_at': config.updated_at.isoformat()
        }

        # Publish to message queue
        message_queue.publish('config_changes', event)

3. Change Propagation Service

Responsibilities:

  • Process configuration change events
  • Notify subscribed services
  • Handle webhook delivery
  • Retry failed notifications

Key Design Decisions:

  • Event-Driven: Process change events from message queue
  • Webhook Delivery: Send HTTP webhooks to services
  • Retry Logic: Retry failed notifications
  • Batching: Batch notifications for efficiency

Implementation:

class ChangePropagationService:
    def __init__(self):
        self.message_queue = MessageQueue()
        self.db = Database()
        self.webhook_client = WebhookClient()

    def process_change_event(self, event):
        service_name = event['service_name']
        environment = event['environment']
        config_key = event['config_key']

        # Get all subscriptions for this key
        subscriptions = self.db.get_subscriptions(
            service_name=service_name,
            environment=environment,
            config_key=config_key
        )

        # Notify each subscriber
        for subscription in subscriptions:
            self.notify_subscriber(subscription, event)

    def notify_subscriber(self, subscription, event):
        if subscription.webhook_url:
            # Send webhook
            try:
                self.webhook_client.post(
                    subscription.webhook_url,
                    json={
                        'event_type': 'config_change',
                        'service_name': event['service_name'],
                        'environment': event['environment'],
                        'config_key': event['config_key'],
                        'version': event['version'],
                        'timestamp': event['updated_at']
                    },
                    timeout=5
                )

                # Update last notified
                self.db.update_subscription_notified(
                    subscription.subscription_id
                )
            except Exception as e:
                # Queue for retry
                self.queue_retry(subscription, event, e)
        else:
            # Publish to service-specific queue
            queue_name = f"config_changes:{subscription.service_name}"
            self.message_queue.publish(queue_name, event)

    def queue_retry(self, subscription, event, error):
        retry_job = {
            'subscription_id': subscription.subscription_id,
            'event': event,
            'error': str(error),
            'retry_count': 0,
            'max_retries': 3
        }

        # Queue with delay
        self.message_queue.publish_delayed(
            'config_notification_retry',
            retry_job,
            delay_seconds=60
        )

Detailed Design

LRU Cache Eviction Strategy

Challenge: Evict least recently used entries when cache is full

Solution:

  • OrderedDict: Use OrderedDict to track access order
  • Move to End: Move accessed items to end
  • Pop from Front: Evict from front (least recently used)

Implementation:

class LRUCache:
    def __init__(self, capacity):
        self.capacity = capacity
        self.cache = OrderedDict()

    def get(self, key):
        if key not in self.cache:
            return None

        # Move to end (most recently used)
        self.cache.move_to_end(key)
        return self.cache[key]

    def put(self, key, value):
        if key in self.cache:
            # Update and move to end
            self.cache[key] = value
            self.cache.move_to_end(key)
        else:
            # Add new
            if len(self.cache) >= self.capacity:
                # Evict least recently used (first item)
                self.cache.popitem(last=False)

            self.cache[key] = value

Distributed Cache Consistency

Challenge: Keep multiple cache instances consistent

Solution:

  • Cache Invalidation: Invalidate on update
  • Event-Driven: Use message queue for invalidation
  • Eventual Consistency: Accept eventual consistency

Implementation:

class DistributedCacheManager:
    def __init__(self):
        self.cache_instances = [
            LRUCache(capacity=1000000) for _ in range(10)
        ]
        self.message_queue = MessageQueue()
        self.setup_invalidation_listener()

    def get_cache_instance(self, key):
        # Consistent hashing to select instance
        hash_value = hash(key)
        instance_index = hash_value % len(self.cache_instances)
        return self.cache_instances[instance_index]

    def get(self, service_name, environment, config_key):
        cache_key = f"{service_name}:{environment}:{config_key}"
        instance = self.get_cache_instance(cache_key)
        return instance.get(cache_key)

    def put(self, service_name, environment, config_key, value):
        cache_key = f"{service_name}:{environment}:{config_key}"
        instance = self.get_cache_instance(cache_key)
        instance.put(cache_key, value)

    def invalidate(self, service_name, environment, config_key):
        cache_key = f"{service_name}:{environment}:{config_key}"

        # Invalidate in all instances (broadcast)
        for instance in self.cache_instances:
            instance.delete(cache_key)

        # Publish invalidation event
        self.message_queue.publish('cache_invalidation', {
            'cache_key': cache_key
        })

    def setup_invalidation_listener(self):
        # Listen for invalidation events from other instances
        self.message_queue.subscribe('cache_invalidation', self.handle_invalidation)

    def handle_invalidation(self, event):
        cache_key = event['cache_key']
        # Invalidate in this instance
        for instance in self.cache_instances:
            instance.delete(cache_key)

Configuration Encryption

Challenge: Encrypt sensitive configuration values

Solution:

  • AES Encryption: Use AES-256 for encryption
  • Key Management: Use key management service
  • Transparent Decryption: Decrypt on read automatically

Implementation:

class EncryptionService:
    def __init__(self):
        self.key_manager = KeyManager()
        self.algorithm = 'AES-256-GCM'

    def encrypt(self, plaintext):
        # Get encryption key
        key = self.key_manager.get_encryption_key()

        # Generate IV
        iv = os.urandom(12)

        # Encrypt
        cipher = Cipher(algorithms.AES(key), modes.GCM(iv))
        encryptor = cipher.encryptor()
        ciphertext = encryptor.update(plaintext.encode()) + encryptor.finalize()

        # Combine IV + ciphertext + tag
        encrypted = iv + ciphertext + encryptor.tag

        # Base64 encode
        return base64.b64encode(encrypted).decode()

    def decrypt(self, ciphertext):
        # Base64 decode
        encrypted = base64.b64decode(ciphertext)

        # Extract components
        iv = encrypted[:12]
        tag = encrypted[-16:]
        ciphertext_data = encrypted[12:-16]

        # Get decryption key
        key = self.key_manager.get_encryption_key()

        # Decrypt
        cipher = Cipher(algorithms.AES(key), modes.GCM(iv, tag))
        decryptor = cipher.decryptor()
        plaintext = decryptor.update(ciphertext_data) + decryptor.finalize()

        return plaintext.decode()

Scalability Considerations

Horizontal Scaling

Configuration Service:

  • Stateless service, horizontally scalable
  • Multiple instances behind load balancer
  • Shared cache instances or distributed cache
  • Database connection pooling

Cache Layer:

  • Multiple cache instances
  • Consistent hashing for key distribution
  • Cache invalidation via message queue

Caching Strategy

LRU Cache:

  • Capacity: 1M keys per instance
  • Eviction: LRU algorithm
  • No TTL: Invalidate on update
  • Distributed: Multiple instances with consistent hashing

Cache Hit Rate Optimization:

  • Warm-up: Pre-load popular configurations
  • Batch Reads: Reduce cache misses
  • Cache Size: Large enough for hot data

Security Considerations

Configuration Encryption

  • Sensitive Data: Encrypt passwords, API keys, tokens
  • Key Management: Use key management service
  • Access Control: Restrict who can read encrypted configs

Access Control

  • Authentication: Authenticate all requests
  • Authorization: Role-based access control
  • Audit Logging: Log all configuration changes

Monitoring & Observability

Key Metrics

System Metrics:

  • Cache hit rate
  • Cache size
  • Read latency (p50, p95, p99)
  • Write latency (p50, p95, p99)
  • Configuration update rate
  • Change propagation latency

Business Metrics:

  • Total configurations
  • Total services
  • Configuration reads per second
  • Configuration updates per day
  • Cache efficiency

Logging

  • Structured Logging: JSON logs for parsing
  • Configuration Events: Log all reads and writes
  • Cache Events: Log cache hits and misses
  • Error Logging: Log errors with context

Alerting

  • Low Cache Hit Rate: Alert if hit rate < 90%
  • High Latency: Alert if p95 latency > 10ms
  • High Error Rate: Alert if error rate > 1%
  • Cache Full: Alert if cache utilization > 95%

Trade-offs and Optimizations

Trade-offs

1. Cache Size: Large vs Small

  • Large: Higher hit rate, more memory
  • Small: Lower memory, lower hit rate
  • Decision: 1M keys per instance (balance)

2. Cache Consistency: Strong vs Eventual

  • Strong: More complex, higher latency
  • Eventual: Simpler, lower latency
  • Decision: Eventual consistency with invalidation

3. Change Propagation: Immediate vs Batch

  • Immediate: Lower latency, higher load
  • Batch: Lower load, higher latency
  • Decision: Immediate for critical configs, batch for others

4. Encryption: Always vs On-Demand

  • Always: More secure, higher overhead
  • On-Demand: Lower overhead, less secure
  • Decision: On-demand encryption for sensitive data

Optimizations

1. Cache Warming

  • Pre-load popular configurations
  • Reduce initial cache misses
  • Improve hit rate

2. Batch Reads

  • Read multiple configs in one query
  • Reduce database load
  • Improve throughput

3. Connection Pooling

  • Reuse database connections
  • Reduce connection overhead
  • Improve performance

4. Compression

  • Compress large configuration values
  • Reduce storage and bandwidth
  • Improve cache efficiency

What Interviewers Look For

Caching Skills

  1. LRU Cache Implementation
    • Hash map + doubly linked list
    • O(1) operations
    • Proper eviction logic
    • Red Flags: Inefficient implementation, wrong complexity
  2. Cache Strategy Understanding
    • Cache-aside pattern
    • Write-through vs write-back
    • Cache invalidation strategies
    • Red Flags: No cache strategy, poor invalidation
  3. Cache Performance
    • High hit rate design
    • Low latency operations
    • Memory efficiency
    • Red Flags: Low hit rate, high latency

System Design Skills

  1. Change Propagation
    • Event-driven architecture
    • Pub/sub patterns
    • Real-time updates
    • Red Flags: Polling, no real-time updates
  2. Multi-Service Support
    • Service isolation
    • Configuration namespacing
    • Red Flags: No isolation, conflicts
  3. Scalability Design
    • Horizontal scaling
    • Load distribution
    • Red Flags: Vertical scaling only, bottlenecks

Problem-Solving Approach

  1. Trade-off Analysis
    • Cache size vs memory
    • Consistency vs latency
    • Red Flags: No trade-off discussion
  2. Edge Cases
    • Cache misses
    • Configuration conflicts
    • Service failures
    • Red Flags: Ignoring edge cases
  3. Performance Optimization
    • Cache warming
    • Batch operations
    • Red Flags: No optimization, poor performance

Code Quality

  1. Implementation Correctness
    • Correct LRU logic
    • Proper cache management
    • Red Flags: Bugs, incorrect logic
  2. Thread Safety
    • Safe concurrent access
    • Proper synchronization
    • Red Flags: Race conditions, no synchronization

Meta-Specific Focus

  1. Caching Expertise
    • Deep understanding of caching
    • Performance optimization
    • Key: Show caching knowledge
  2. Distributed Systems
    • Change propagation
    • Multi-service architecture
    • Key: Demonstrate distributed systems understanding

Summary

Designing a configuration service with LRU cache requires careful consideration of:

  1. LRU Cache: Efficient in-memory cache with LRU eviction
  2. Cache-Aside Pattern: Check cache first, then database
  3. Change Propagation: Real-time notification of configuration changes
  4. Configuration Versioning: Track all configuration changes
  5. Multi-Service Support: Serve multiple microservices
  6. Encryption: Encrypt sensitive configuration values
  7. Scalability: Handle 100K+ reads per second
  8. High Cache Hit Rate: > 95% cache hit rate
  9. Low Latency: Sub-millisecond cache reads
  10. Configuration Validation: Validate configuration schemas

Key architectural decisions:

  • LRU Cache for fast configuration reads
  • Cache-Aside Pattern for cache management
  • Event-Driven Change Propagation for real-time updates
  • Sharded Database for configuration storage
  • Distributed Cache for horizontal scaling
  • Encryption Service for sensitive data
  • Message Queue for change notifications
  • Horizontal Scaling for all services

The system handles 100,000 configuration reads per second with sub-millisecond latency, maintains > 95% cache hit rate, and provides real-time configuration change propagation to all subscribed services.
