Introduction

Designing a simple chat application is a system design interview question that tests your ability to model messaging systems, handle message persistence, and manage conversation state. This question focuses on:

• Object-oriented modeling: Users, Messages, Conversations
• Message queues: Local message handling
• Persistence: Storing messages and conversations
• State management: Read/unread status, online/offline

This guide covers the design of a simple chat application with proper entity modeling and message handling.

Table of Contents

1. Problem Statement
2. Requirements
3. Data Modeling
4. Class Design
5. Message Handling
6. Read/Unread State
7. Message History
8. Implementation
9. Summary

Problem Statement

Design a simple chat application that:

1. Manages users and conversations
2. Handles messages (send, receive, store)
3. Tracks read/unread status
4. Stores message history for retrieval
5. Supports conversations (1-on-1, group)
6. Handles online/offline status

Scale Requirements:

• Support 1K-100K users
• Support 10K-1M messages
• Fast message delivery: < 50ms
• Efficient history retrieval

Requirements

Functional Requirements

1. Send Message: Send message to user or group
2. Receive Message: Receive and display messages
3. Mark as Read: Mark messages as read
4. Get History: Retrieve conversation history
5. Create Conversation: Start new conversation
6. Get Unread Count: Get unread message count

Non-Functional Requirements

Performance:

• Fast message delivery
• Efficient history retrieval
• Quick read status updates

Consistency:

• No message loss
• Accurate read status
• Correct message ordering

Data Modeling

Database Schema

CREATE TABLE users (
    user_id BIGINT PRIMARY KEY AUTO_INCREMENT,
    username VARCHAR(50) UNIQUE NOT NULL,
    email VARCHAR(100) UNIQUE NOT NULL,
    status VARCHAR(20) DEFAULT 'offline',  -- online, offline, away
    last_seen TIMESTAMP NULL,
    created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    INDEX idx_username (username)
);

CREATE TABLE conversations (
    conversation_id BIGINT PRIMARY KEY AUTO_INCREMENT,
    conversation_type VARCHAR(20) DEFAULT 'direct',  -- direct, group
    name VARCHAR(100) NULL,  -- For group chats
    created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    updated_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
);

CREATE TABLE conversation_participants (
    participant_id BIGINT PRIMARY KEY AUTO_INCREMENT,
    conversation_id BIGINT NOT NULL,
    user_id BIGINT NOT NULL,
    joined_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    last_read_at TIMESTAMP NULL,
    UNIQUE KEY unique_conversation_user (conversation_id, user_id),
    INDEX idx_user_id (user_id),
    INDEX idx_conversation_id (conversation_id),
    FOREIGN KEY (conversation_id) REFERENCES conversations(conversation_id),
    FOREIGN KEY (user_id) REFERENCES users(user_id)
);

CREATE TABLE messages (
    message_id BIGINT PRIMARY KEY AUTO_INCREMENT,
    conversation_id BIGINT NOT NULL,
    sender_id BIGINT NOT NULL,
    content TEXT NOT NULL,
    message_type VARCHAR(20) DEFAULT 'text',  -- text, image, file
    created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    INDEX idx_conversation_id (conversation_id),
    INDEX idx_created_at (created_at),
    INDEX idx_sender_id (sender_id),
    FOREIGN KEY (conversation_id) REFERENCES conversations(conversation_id),
    FOREIGN KEY (sender_id) REFERENCES users(user_id)
);

CREATE TABLE message_reads (
    read_id BIGINT PRIMARY KEY AUTO_INCREMENT,
    message_id BIGINT NOT NULL,
    user_id BIGINT NOT NULL,
    read_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    UNIQUE KEY unique_message_user (message_id, user_id),
    INDEX idx_message_id (message_id),
    INDEX idx_user_id (user_id),
    FOREIGN KEY (message_id) REFERENCES messages(message_id),
    FOREIGN KEY (user_id) REFERENCES users(user_id)
);

Data Model Classes

from enum import Enum
from datetime import datetime
from typing import Optional, List
from dataclasses import dataclass

class ConversationType(Enum):
    DIRECT = "direct"
    GROUP = "group"

class UserStatus(Enum):
    ONLINE = "online"
    OFFLINE = "offline"
    AWAY = "away"

@dataclass
class User:
    user_id: Optional[int]
    username: str
    email: str
    status: UserStatus
    last_seen: Optional[datetime]

@dataclass
class Conversation:
    conversation_id: Optional[int]
    conversation_type: ConversationType
    name: Optional[str]
    created_at: datetime
    updated_at: datetime
    participants: List[int]  # user_ids

@dataclass
class Message:
    message_id: Optional[int]
    conversation_id: int
    sender_id: int
    content: str
    message_type: str
    created_at: datetime
    read_by: List[int] = None  # user_ids who read

    def __post_init__(self):
        if self.read_by is None:
            self.read_by = []

Class Design

Chat Application

class ChatApplication:
    def __init__(self, db):
        self.db = db
        self.message_queue = {}  # conversation_id -> List[Message]
        self.online_users = set()  # user_id set

    def create_user(self, username: str, email: str) -> User:
        """Create new user."""
        user = User(
            user_id=None,
            username=username,
            email=email,
            status=UserStatus.OFFLINE,
            last_seen=None
        )
        return self.db.create_user(user)

    def create_conversation(self, user_ids: List[int],
                           conversation_type: ConversationType = ConversationType.DIRECT,
                           name: Optional[str] = None) -> Conversation:
        """Create new conversation."""
        if conversation_type == ConversationType.DIRECT and len(user_ids) != 2:
            raise ValueError("Direct conversation requires exactly 2 users")

        conversation = Conversation(
            conversation_id=None,
            conversation_type=conversation_type,
            name=name,
            created_at=datetime.now(),
            updated_at=datetime.now(),
            participants=user_ids
        )

        conversation = self.db.create_conversation(conversation)

        # Add participants
        for user_id in user_ids:
            self.db.add_participant(conversation.conversation_id, user_id)

        return conversation

    def send_message(self, conversation_id: int, sender_id: int,
                    content: str, message_type: str = 'text') -> Message:
        """Send message to conversation."""
        # Validate conversation and sender
        conversation = self.db.get_conversation(conversation_id)
        if not conversation:
            raise ValueError("Conversation not found")

        if sender_id not in conversation.participants:
            raise ValueError("User not in conversation")

        # Create message
        message = Message(
            message_id=None,
            conversation_id=conversation_id,
            sender_id=sender_id,
            content=content,
            message_type=message_type,
            created_at=datetime.now()
        )

        message = self.db.create_message(message)

        # Update conversation timestamp
        conversation.updated_at = datetime.now()
        self.db.update_conversation(conversation)

        # Add to message queue for real-time delivery
        if conversation_id not in self.message_queue:
            self.message_queue[conversation_id] = []
        self.message_queue[conversation_id].append(message)

        return message

    def get_messages(self, conversation_id: int, user_id: int,
                    limit: int = 50, offset: int = 0) -> List[Message]:
        """Get conversation messages."""
        # Validate user is participant
        if not self.db.is_participant(conversation_id, user_id):
            raise ValueError("User not in conversation")

        messages = self.db.get_messages(conversation_id, limit=limit, offset=offset)

        # Mark as read for this user
        unread_messages = [m for m in messages if user_id not in m.read_by]
        for message in unread_messages:
            self.mark_as_read(message.message_id, user_id)

        return messages

    def mark_as_read(self, message_id: int, user_id: int) -> bool:
        """Mark message as read."""
        message = self.db.get_message(message_id)
        if not message:
            return False

        # Check if already read
        if self.db.is_message_read(message_id, user_id):
            return True

        # Mark as read
        self.db.mark_message_read(message_id, user_id)

        # Update participant's last_read_at
        self.db.update_participant_last_read(message.conversation_id, user_id)

        return True

    def mark_conversation_as_read(self, conversation_id: int, user_id: int):
        """Mark all messages in conversation as read."""
        # Get unread messages
        unread_messages = self.db.get_unread_messages(conversation_id, user_id)

        for message in unread_messages:
            self.mark_as_read(message.message_id, user_id)

        # Update last_read_at
        self.db.update_participant_last_read(conversation_id, user_id)

    def get_unread_count(self, user_id: int) -> dict:
        """Get unread message count per conversation."""
        conversations = self.db.get_user_conversations(user_id)
        unread_counts = {}

        for conversation in conversations:
            count = self.db.get_unread_count(conversation.conversation_id, user_id)
            if count > 0:
                unread_counts[conversation.conversation_id] = count

        return unread_counts

    def get_conversation_history(self, conversation_id: int, user_id: int,
                                limit: int = 50) -> List[Message]:
        """Get conversation history."""
        if not self.db.is_participant(conversation_id, user_id):
            raise ValueError("User not in conversation")

        return self.db.get_messages(conversation_id, limit=limit)

    def set_user_status(self, user_id: int, status: UserStatus):
        """Set user online/offline status."""
        user = self.db.get_user(user_id)
        if not user:
            return

        user.status = status
        user.last_seen = datetime.now()
        self.db.update_user(user)

        if status == UserStatus.ONLINE:
            self.online_users.add(user_id)
        else:
            self.online_users.discard(user_id)

Message Handling

Local Message Queue

class ChatApplication:
    def __init__(self, db):
        # ... existing code ...
        self.message_queue = {}  # conversation_id -> queue.Queue

    def send_message(self, conversation_id: int, sender_id: int, content: str) -> Message:
        """Send message with queue."""
        # ... create message ...

        # Add to queue for delivery
        if conversation_id not in self.message_queue:
            self.message_queue[conversation_id] = queue.Queue()

        self.message_queue[conversation_id].put(message)

        # Notify participants (in real system, use WebSocket/SSE)
        self._notify_participants(conversation_id, message)

        return message

    def get_pending_messages(self, conversation_id: int, user_id: int) -> List[Message]:
        """Get pending messages from queue."""
        if conversation_id not in self.message_queue:
            return []

        messages = []
        queue_obj = self.message_queue[conversation_id]

        while not queue_obj.empty():
            try:
                message = queue_obj.get_nowait()
                # Only return messages not from this user
                if message.sender_id != user_id:
                    messages.append(message)
            except queue.Empty:
                break

        return messages

    def _notify_participants(self, conversation_id: int, message: Message):
        """Notify conversation participants of new message."""
        conversation = self.db.get_conversation(conversation_id)
        for user_id in conversation.participants:
            if user_id != message.sender_id and user_id in self.online_users:
                # Send notification (in real system, push via WebSocket)
                pass

Read/Unread State

Efficient Read Tracking

class ChatApplication:
    def get_unread_messages(self, conversation_id: int, user_id: int) -> List[Message]:
        """Get unread messages for user."""
        # Get participant's last_read_at
        participant = self.db.get_participant(conversation_id, user_id)
        if not participant or not participant.last_read_at:
            # No read timestamp, all messages are unread
            return self.db.get_messages(conversation_id)

        # Get messages after last_read_at
        return self.db.get_messages_after(conversation_id, participant.last_read_at)

    def get_unread_count_fast(self, conversation_id: int, user_id: int) -> int:
        """Fast unread count using last_read_at."""
        participant = self.db.get_participant(conversation_id, user_id)
        if not participant or not participant.last_read_at:
            return self.db.get_message_count(conversation_id)

        return self.db.get_message_count_after(conversation_id, participant.last_read_at)

Message History

Pagination

class ChatApplication:
    def get_message_history(self, conversation_id: int, user_id: int,
                           page: int = 1, page_size: int = 50) -> dict:
        """Get message history with pagination."""
        if not self.db.is_participant(conversation_id, user_id):
            raise ValueError("User not in conversation")

        offset = (page - 1) * page_size
        messages = self.db.get_messages(conversation_id, limit=page_size, offset=offset)
        total = self.db.get_message_count(conversation_id)

        return {
            'messages': messages,
            'page': page,
            'page_size': page_size,
            'total': total,
            'total_pages': (total + page_size - 1) // page_size
        }

Implementation

Complete Example

# Initialize
db = Database()
chat_app = ChatApplication(db)

# Create users
user1 = chat_app.create_user("alice", "alice@example.com")
user2 = chat_app.create_user("bob", "bob@example.com")

# Create conversation
conversation = chat_app.create_conversation([user1.user_id, user2.user_id])

# Send messages
message1 = chat_app.send_message(conversation.conversation_id, user1.user_id, "Hello!")
message2 = chat_app.send_message(conversation.conversation_id, user2.user_id, "Hi there!")

# Get messages
messages = chat_app.get_messages(conversation.conversation_id, user1.user_id)

# Mark as read
chat_app.mark_as_read(message2.message_id, user1.user_id)

# Get unread count
unread = chat_app.get_unread_count(user1.user_id)

What Interviewers Look For

Object-Oriented Modeling Skills

1. Entity Design
   • Proper modeling of User, Message, Conversation
   • Clear relationships and responsibilities
   • Red Flags: Unclear entities, poor relationships
2. State Management
   • Read/unread state tracking
   • Online/offline status
   • Red Flags: Missing state, incorrect tracking

Message Handling

1. Message Queue Design
   • Local queue implementation
   • Message delivery logic
   • Red Flags: No queue, incorrect delivery
2. Persistence Strategy
   • Message storage
   • History retrieval
   • Red Flags: No persistence, inefficient retrieval

Problem-Solving Approach

1. Read/Unread Tracking
   • Efficient tracking mechanism
   • last_read_at approach
   • Red Flags: Inefficient tracking, wrong approach
2. Message History
   • Pagination implementation
   • Efficient queries
   • Red Flags: No pagination, slow queries
3. Edge Cases
   • Group conversations
   • Message ordering
   • Concurrent messages
   • Red Flags: Ignoring edge cases

Code Quality

1. Data Consistency
   • Accurate read status
   • Correct message ordering
   • Red Flags: Wrong status, incorrect ordering
2. Error Handling
   • Validation of operations
   • Meaningful errors
   • Red Flags: No validation, unclear errors

Interview Focus

1. Local System Design
   • No distributed messaging
   • Focus on data structures
   • Key: Show local system understanding
2. State Management
   • Proper state tracking
   • Efficient updates
   • Key: Demonstrate state management skills

Summary

Key Takeaways

1. Entity Modeling: Users, Conversations, Messages, Participants
2. Message Handling: Send, receive, store, queue
3. Read/Unread State: Track with last_read_at timestamp
4. Message History: Pagination for efficient retrieval
5. State Management: Online/offline, read status

Common Interview Questions

1. How would you model Users, Messages, and Conversations?
   • Users: user_id, username, status
   • Messages: message_id, conversation_id, sender_id, content
   • Conversations: conversation_id, type, participants
2. How would you mark messages as read/unread?
   • Track last_read_at per participant
   • Messages after last_read_at are unread
   • Update on read action
3. How would you handle message history retrieval?
   • Pagination: limit/offset
   • Index on conversation_id, created_at
   • Efficient queries with proper indexes

Understanding chat application design is crucial for Meta interviews focusing on:

• Object-oriented modeling
• Message handling
• State management
• Persistence
• Read/unread tracking
