Introduction

Designing a text editor is a system design interview question that tests your understanding of efficient data structures for text manipulation, command patterns, and memory management. This question focuses on:

  • Data structures: Rope, gap buffer, piece table
  • Command handling: Insert, delete, undo/redo
  • Memory efficiency: Handling large files
  • Performance: Fast insertions/deletions

This guide covers the design of a text editor with efficient data structures and undo/redo functionality.

Table of Contents

  1. Problem Statement
  2. Requirements
  3. Data Structure Options
  4. Gap Buffer Implementation
  5. Rope Implementation
  6. Command Pattern
  7. Undo/Redo System
  8. Implementation
  9. Summary

Problem Statement

Design a text editor that:

  1. Handles text insertion efficiently
  2. Handles text deletion efficiently
  3. Supports undo/redo operations
  4. Handles large files (MB to GB)
  5. Supports cursor movement and selection
  6. Provides fast operations (< 10ms for typical operations)

Scale Requirements:

  • Support files from KB to GB
  • Fast insert/delete: O(log n) or better
  • Memory efficient
  • Handle millions of operations

Requirements

Functional Requirements

  1. Insert Text: Insert text at cursor position
  2. Delete Text: Delete text at cursor or selection
  3. Move Cursor: Move cursor position
  4. Select Text: Select text range
  5. Undo: Undo last operation
  6. Redo: Redo undone operation
  7. Get Text: Retrieve full or partial text

Non-Functional Requirements

Performance:

  • Fast insertions: O(log n) or O(1) amortized
  • Fast deletions: O(log n) or O(1) amortized
  • Efficient memory usage

Reliability:

  • Correct undo/redo
  • No data loss
  • Handle edge cases

Data Structure Options

1. Simple String (Naive)

  • Pros: Simple, O(1) access
  • Cons: O(n) insert/delete
  • Use: Small files only
  • Pros: O(1) insert/delete at cursor, simple
  • Cons: O(n) for cursor movement far from gap
  • Use: Good for typical editing

3. Rope (Best for Large Files)

  • Pros: O(log n) operations, handles large files
  • Cons: More complex implementation
  • Use: Large files, complex operations

4. Piece Table

  • Pros: Efficient for large files, good undo
  • Cons: Complex implementation
  • Use: Professional editors

Gap Buffer Implementation

Gap Buffer Data Structure

class GapBuffer:
    def __init__(self, initial_text: str = ""):
        # Buffer with gap in the middle
        self.buffer = list(initial_text)
        self.gap_start = len(initial_text)
        self.gap_end = len(initial_text) + 10  # Initial gap size
        self.buffer.extend(['\0'] * 10)  # Gap represented by null chars
        self.cursor = 0

    def insert(self, text: str):
        """Insert text at cursor position."""
        for char in text:
            # Move gap to cursor if needed
            self._move_gap_to_cursor()

            # Insert character
            self.buffer[self.gap_start] = char
            self.gap_start += 1
            self.cursor += 1

            # Expand gap if needed
            if self.gap_start >= self.gap_end:
                self._expand_gap()

    def delete(self, count: int = 1):
        """Delete characters before cursor."""
        if count <= 0:
            return

        # Move gap to cursor
        self._move_gap_to_cursor()

        # Delete by moving gap forward
        delete_count = min(count, self.cursor)
        self.gap_start -= delete_count
        self.cursor -= delete_count

    def delete_forward(self, count: int = 1):
        """Delete characters after cursor."""
        if count <= 0:
            return

        # Move gap to cursor
        self._move_gap_to_cursor()

        # Delete by moving gap end
        available = len(self.buffer) - self.gap_end
        delete_count = min(count, available)
        self.gap_end += delete_count

    def move_cursor(self, position: int):
        """Move cursor to position."""
        self.cursor = max(0, min(position, len(self)))

    def get_text(self) -> str:
        """Get full text."""
        return ''.join(self.buffer[:self.gap_start] + self.buffer[self.gap_end:])

    def get_text_range(self, start: int, end: int) -> str:
        """Get text in range."""
        text = self.get_text()
        return text[start:end]

    def _move_gap_to_cursor(self):
        """Move gap to cursor position."""
        if self.cursor == self.gap_start:
            return  # Gap already at cursor

        if self.cursor < self.gap_start:
            # Move gap left
            move_count = self.gap_start - self.cursor
            self.buffer[self.gap_end - move_count:self.gap_end] = \
                self.buffer[self.cursor:self.gap_start]
            self.gap_start = self.cursor
            self.gap_end -= move_count
        else:
            # Move gap right
            move_count = self.cursor - self.gap_start
            self.buffer[self.gap_start:self.gap_start + move_count] = \
                self.buffer[self.gap_end:self.gap_end + move_count]
            self.gap_start = self.cursor
            self.gap_end += move_count

    def _expand_gap(self):
        """Expand gap size."""
        expansion = max(10, len(self.buffer) // 2)
        insert_pos = self.gap_start
        self.buffer[insert_pos:insert_pos] = ['\0'] * expansion
        self.gap_end += expansion

    def __len__(self) -> int:
        """Get text length."""
        return len(self.buffer) - (self.gap_end - self.gap_start)

Rope Implementation

Rope Data Structure

class RopeNode:
    def __init__(self, text: str = "", left=None, right=None):
        self.text = text
        self.left = left
        self.right = right
        self.length = len(text)
        if left:
            self.length += left.length
        if right:
            self.length += right.length

    def get_char(self, index: int) -> str:
        """Get character at index."""
        if self.left:
            if index < self.left.length:
                return self.left.get_char(index)
            index -= self.left.length

        if index < len(self.text):
            return self.text[index]

        if self.right:
            return self.right.get_char(index - len(self.text))

        raise IndexError("Index out of range")

    def get_text(self, start: int = 0, end: int = None) -> str:
        """Get text in range."""
        if end is None:
            end = self.length

        result = []
        if self.left and start < self.left.length:
            left_end = min(end, self.left.length)
            result.append(self.left.get_text(start, left_end))
            start = max(0, start - self.left.length)
            end -= self.left.length

        if start < len(self.text):
            text_start = max(0, start)
            text_end = min(len(self.text), end)
            result.append(self.text[text_start:text_end])
            end -= len(self.text)

        if self.right and end > 0:
            result.append(self.right.get_text(0, end))

        return ''.join(result)

class Rope:
    def __init__(self, text: str = ""):
        self.root = RopeNode(text) if text else None
        self.leaf_size = 10  # Max characters per leaf

    def insert(self, position: int, text: str):
        """Insert text at position."""
        if not self.root:
            self.root = RopeNode(text)
            return

        left, right = self._split(self.root, position)
        new_node = RopeNode(text)
        self.root = self._concat(left, self._concat(new_node, right))

    def delete(self, start: int, end: int):
        """Delete text in range."""
        if not self.root:
            return

        left, temp = self._split(self.root, start)
        _, right = self._split(temp, end - start)
        self.root = self._concat(left, right)

    def get_text(self) -> str:
        """Get full text."""
        if not self.root:
            return ""
        return self.root.get_text()

    def _split(self, node: RopeNode, position: int) -> tuple:
        """Split rope at position."""
        if not node:
            return None, None

        if position <= 0:
            return None, node

        if position >= node.length:
            return node, None

        if node.left:
            if position < node.left.length:
                left_left, left_right = self._split(node.left, position)
                return left_left, self._concat(left_right, node.right)
            position -= node.left.length

        if position < len(node.text):
            left_text = node.text[:position]
            right_text = node.text[position:]
            return (
                self._concat(node.left, RopeNode(left_text)),
                RopeNode(right_text, node.right)
            )

        if node.right:
            right_left, right_right = self._split(node.right, position - len(node.text))
            return (
                self._concat(node.left, RopeNode(node.text, None, right_left)),
                right_right
            )

        return node, None

    def _concat(self, left: RopeNode, right: RopeNode) -> RopeNode:
        """Concatenate two ropes."""
        if not left:
            return right
        if not right:
            return left
        return RopeNode("", left, right)

Command Pattern

Command Interface

from abc import ABC, abstractmethod

class Command(ABC):
    @abstractmethod
    def execute(self):
        pass

    @abstractmethod
    def undo(self):
        pass

class InsertCommand(Command):
    def __init__(self, editor, position: int, text: str):
        self.editor = editor
        self.position = position
        self.text = text

    def execute(self):
        self.editor.insert(self.position, self.text)

    def undo(self):
        self.editor.delete(self.position, self.position + len(self.text))

class DeleteCommand(Command):
    def __init__(self, editor, start: int, end: int):
        self.editor = editor
        self.start = start
        self.end = end
        self.deleted_text = None

    def execute(self):
        self.deleted_text = self.editor.get_text_range(self.start, self.end)
        self.editor.delete(self.start, self.end)

    def undo(self):
        if self.deleted_text:
            self.editor.insert(self.start, self.deleted_text)

Undo/Redo System

Undo/Redo Manager

class TextEditor:
    def __init__(self, initial_text: str = ""):
        self.buffer = GapBuffer(initial_text)
        self.undo_stack = []
        self.redo_stack = []
        self.cursor = 0

    def insert(self, position: int, text: str):
        """Insert text with undo support."""
        command = InsertCommand(self, position, text)
        command.execute()
        self.undo_stack.append(command)
        self.redo_stack.clear()  # Clear redo on new action
        self.cursor = position + len(text)

    def delete(self, start: int, end: int):
        """Delete text with undo support."""
        command = DeleteCommand(self, start, end)
        command.execute()
        self.undo_stack.append(command)
        self.redo_stack.clear()
        self.cursor = start

    def undo(self):
        """Undo last operation."""
        if not self.undo_stack:
            return

        command = self.undo_stack.pop()
        command.undo()
        self.redo_stack.append(command)

    def redo(self):
        """Redo last undone operation."""
        if not self.redo_stack:
            return

        command = self.redo_stack.pop()
        command.execute()
        self.undo_stack.append(command)

    def get_text(self) -> str:
        """Get full text."""
        return self.buffer.get_text()

    def get_text_range(self, start: int, end: int) -> str:
        """Get text in range."""
        return self.buffer.get_text_range(start, end)

Implementation

Complete Example

# Create editor
editor = TextEditor("Hello World")

# Insert text
editor.insert(5, ", Beautiful")
print(editor.get_text())  # "Hello, Beautiful World"

# Delete text
editor.delete(5, 16)
print(editor.get_text())  # "Hello World"

# Undo
editor.undo()
print(editor.get_text())  # "Hello, Beautiful World"

# Redo
editor.redo()
print(editor.get_text())  # "Hello World"

What Interviewers Look For

Data Structures Knowledge

  1. Understanding of Text Data Structures
    • Gap buffer vs Rope trade-offs
    • When to use which structure
    • Complexity analysis
    • Red Flags: No understanding of trade-offs, wrong choice
  2. Algorithm Efficiency
    • O(1) vs O(log n) operations
    • Memory efficiency
    • Red Flags: Inefficient algorithms, high memory usage

Command Pattern Implementation

  1. Undo/Redo Design
    • Command pattern usage
    • Stack-based implementation
    • Red Flags: No undo/redo, incorrect implementation
  2. Command Encapsulation
    • Proper command interface
    • Execute/undo methods
    • Red Flags: Poor encapsulation, no undo

Problem-Solving Approach

  1. Large File Handling
    • Memory-efficient approaches
    • Lazy loading considerations
    • Red Flags: Loads entire file, memory issues
  2. Performance Optimization
    • Efficient insertions/deletions
    • Cursor movement optimization
    • Red Flags: Slow operations, no optimization

Code Quality

  1. Algorithm Implementation
    • Correct gap buffer/rope implementation
    • Proper edge case handling
    • Red Flags: Incorrect implementation, bugs
  2. Memory Management
    • Efficient memory usage
    • No memory leaks
    • Red Flags: High memory usage, leaks

Interview Focus

  1. Data Structures Mastery
    • Deep understanding of structures
    • Trade-off analysis
    • Key: Show strong CS fundamentals
  2. Algorithmic Thinking
    • Complexity analysis
    • Optimization strategies
    • Key: Demonstrate algorithmic skills

Summary

Key Takeaways

  1. Data Structures: Gap buffer (simple), Rope (complex, efficient)
  2. Insert/Delete: O(1) with gap buffer, O(log n) with rope
  3. Undo/Redo: Command pattern with stacks
  4. Large Files: Rope handles GB files efficiently
  5. Memory: Gap buffer expands as needed, rope uses tree structure

Common Interview Questions

  1. How would you efficiently insert/delete text?
    • Gap buffer: O(1) at cursor, move gap as needed
    • Rope: O(log n) with tree structure
  2. How would you implement undo/redo?
    • Command pattern: Each operation is a command
    • Undo stack: Store executed commands
    • Redo stack: Store undone commands
  3. How would you handle large files?
    • Rope: Tree structure, O(log n) operations
    • Piece table: Store original + changes
    • Lazy loading: Load file in chunks

Understanding text editor design is crucial for Meta interviews focusing on:

  • Data structures
  • Algorithms
  • Memory efficiency
  • Command patterns
  • Performance optimization
